PSU 34W PROFESSIONALE 250-700MA NO-DIM
ILLUXTRON
Specifications
| Reference | 05HA03MLMC00 |
|---|---|
| Brand | Illuxtron |
| Family | Professionale |
| Location use | Interior |
| Fixation location | Ceiling recessed, Technical area, Standalone |
| Application | Power-controlled LEDs |
| Shape | Rectangular |
| Colour This is the colour of which the device is mainly composed. | White |
| Type in brand | Transformers / Power |
| Voltage/current | Multiwatt - Multistroom |
| Power factor | >0,95 |
| Operating temperature | -25°C to +40°C |
| IP rating IP stands for "International Potection. The first digit indicates dust density. The second indicates water density. However, if a third digit is included, it refers to the impact resistance or 'I K' value. | IP20 |
| Insulation class | II |
| Dimensions | See picture |
| Length in mm | 146,5 |
| Width in mm | 43,5 |
| Height in mm | 30 |
| Dimmable With a dimmable lighting fixture, you can control the intensity of the light. Usually this is with an external, NOT included dimmer. When in doubt, inquire. | No |
| More technical details | See technical data sheet |
| Weight in kg | 0,122 |
| Warranty | 10 years |
| Forward voltage at 250 mA | 20-50 |
| Forward voltage at 300 mA | 15-50 |
| Forward voltage at 350 mA | 15-50 |
| Forward voltage at 400 mA | 15-50 |
| Forward voltage at 450 mA | 15-50 |
| Forward voltage at 500 mA | 10-50 |
| Forward voltage at 550 mA | 10-50 |
| Forward voltage at 600 mA | 10-50 |
| Forward voltage at 650 mA | 10-49 |
| Forward voltage at 700 mA | 10-48 |
| Power at 250 mA (watt) | 12 |
| Power at 300ma (watt) | 15 |
| Power at 350 mA (watt) | 17 |
| Power at 400 mA (watt) | 20 |
| Power at 450 mA (watt) | 22 |
| Power at 500 mA (watt) | 25 |
| Power at 550 mA (watt) | 27 |
| Power at 600ma (watt) | 30 |
| Power at 650 mA (watt) | 32 |
| Power at 700 mA (watt) | 34 |
| Current output | 0,25 - 0,7 |
| Input voltage (V) | 220-240V |
| Multiwatt | Yes |
| Transformer suitable for | Power-controlled LED lamps |
| Min.-max power (watt) | 12-34 |
| Can trough opening of | 54 |
